Standard Configuration:
|
 |
| Technical Specification | |
| Measuring Range | |
| Acceleration | RMS acceleration measurement, full scale 200 mm/s2 |
| Frequency range 10Hz to 10 kHz | |
| Velocity | RMS vibration velocity, full scale 200 m/s |
| Frequency range 10 Hz to 1 kHz | |
| Displacement | Equivalent peak to peak displacement, full scale 2000 microns |
| Frequency range 10Hz to 500 Hz | |
| Display | LCD, test value in 4 large digits |
| Accelerometer Probe | External piezo-electric accelerometer with magnetic base |
| Sensitivity | 25 mV/g |
| Mix cross ratio | 4.5% |
| Magnetic Base | CZ-4 |
| Data Output | To printer, all test data and spectrogram |
| Memory | 100 test data results and 10 spectrograms |
| Standard | Conforms to ISO 2954 |
| Power Supply | Ni-MH rechargeable batteries 1.25V |
| Battery Capacity | 10 hours continuous operation |
| Operating Temperature | 0 to 45 degrees C |
| Dimensions | 270 x 86 x 47mm |
| Weight | 650 gr |
|
